Deye: 20Kw Three Phase Hybrid Inverter (SUN-20K-SG01HP3-EU-AM2)
$53.2
$103.74
Description Deye: 20Kw Three Phase Hybrid Inverter (SUN-20K-SG01HP3-EU-AM2) Deye: 20Kw Three Phase Hybrid Inverter (SUN-20K-SG01HP3-EU-AM2) (5 Year Warranty) • Battery Voltage Range: 160VDC to 700VDC • Maximum Charging Current: 50A 50A • Maximum Discharging Current: 50A 50A • Number Of Battery Input: 1 • Charging Strategy for Li-Ion Battery: Self adaption to BMS PV String Input Data • Maximum DC Input Power: 26000W • Maximum DC Input Voltage: 1000VDC • Startup Voltage: 180VDC • MPPT Voltage Range: 150VDC to 850VDC • Full Load DC Voltage Range: 500VDC to 850VDC • Rated DC Input Voltage: 600VDC • PV Input Current: 26A 26A • Maximum PV (Isc): 39A 39A • No of MPP Trackers: 2 • Strings per MPP Tracker: 2 AC Output • Rated AC Output and UPS Power: 20000W • Maximum AC Output Power: 22000W • AC Output Rated Current: 30.4A / 29A • Maximum AC Current: 33.4A • Maximum Continuous AC Passthrough: 80A • Peak Power (Off Grid): 1.5 time of rated Power, 10S • Generator Input: 75.8A • AC Couple Current: 75.8A • Power Factor: 0.8 Leading to 0.8 Lagging • Output Frequency and Voltage: 50/60Hz; 3L/N/PE 220/380VAC, 230/400VAC • Grid Type: Three Phase Environment Limit • Operating Temperature Range: -40°C to 60°C • Cooling: Smart Cooling (<45 dB) • Communication with BMS: RS485 / CAN • Ingress Protection: IP65 • Safety Certification: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
