Description Output Output Power Capacity 3500 Watts / 5000 VA Max Configurable Power (Watts) 3500 Watts / 5000 VA Nominal Output Voltage 230V Output Voltage Note Configurable for 220 : 230 or 240 nominal output voltage Output Voltage Distortion Less than 3% Output Frequency (sync to mains) 50/60 Hz /- 3 Hz user adjustable /- 0.1 Other Output Voltages 220, 240V Crest Factor 3 : 1 Double Conversion Online Waveform Type Sine wave Output Connections (2) IEC 320 C19 (Battery Backup) , (4) IEC Jumpers (Battery Backup) , (8) IEC 320 C13 (Battery Backup) Bypass Internal Bypass (Automatic and Manual) Input Nominal Input Voltage 230V Input Frequency 50/60 Hz /- 5 Hz (auto sensing) Input Connections Hard Wire 3-wire Input voltage range for main operations 160 – 280 V Input voltage adjustable range for mains operation 100 – 280 (half load)V Other Input Voltages 220 , 240 Batteries & Runtime Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Included Battery Modules 2 Typical recharge time 2.5 hour(s) Replacement Battery APCRBC140 RBC Quantity 1 Communications & Management Interface Port(s) RJ-45 10/100 Base-T , RJ-45 Serial , Smart-Slot Pre-Installed SmartSlot™ Cards AP9631 Control panel LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : Overload and Bypass Indicators Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Emergency Power Off (EPO) Yes Surge Protection and Filtering Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 Physical Maximum Height 432.0 mm Maximum Width 130.0 mm Maximum Depth 660.0 mm Rack Height 3 U Net Weight 54.43 kg Shipping Weight 63.64 kg Shipping Height 347.0 mm Shipping Width 603.0 mm Shipping Depth 980.0 mm Master Carton Units 1.0 Color Black Units per Pallet 6.0 Environmental Operating Environment 0 – 40 °C Operating Relative Humidity 0 – 95% non-condensing % Operating Elevation 0-3000 meters Storage Temperature -15 – 45 °C Storage Relative Humidity 0 – 95% non-condensing % Storage Elevation 0-15000 meters Audible noise at 1 meter from surface of unit 55.000 dB Online Thermal Dissipation 1057.000 BTU/hr Protection Class IP 20 Conformance Approvals C-tick , CE , EN 50091-1 , EN 50091-2 , EN 55022 Class A , EN 60950 , EN 61000-3-2 , GOST , UL 1778 , VDE Standard warranty 2 years repair or replace , optional extended warranties available , optional on-site warranties available Sustainable Offer Status RoHS Compliant
