FeaturesRemovable LCD control module with multiple communications servers and ATM.Built-in Bluetooth for mobile monitoring (Android App is available).Replaceable fan design for ease of maintenance.Supply load from Grid or PV, even battery is not available.Configurable AC/PV output usage timer and prioritization.Selectable high-power charging current.Selectable input voltage range for home appliances and personal computers.Compatible to Utility Mains or generator input.Auto restart while AC is recovering.Cold start function.Technical DataModel: OG 5.48.Rated Power: 5000VA/5000W.InputVoltage: 230 VAC.Selectable Voltage Range: 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances).Frequency Range: 50 Hz/60 Hz (Auto sensing).OutputAC Voltage Regulation (Batt. Mode: 230VAC ± 5%.Surge Power: 10000VA.Efficiency (Peak): 93%.Transfer Time: 15 ms (For Personal Computers); 20 ms (For Home Appliances).Waveform: Pure sine wave.BatteryBattery Voltage: 48 VDC.Floating Charge Voltage: 54 VDC.Overcharge Protection: 63 VDC.Solar Charger & AC ChargerSolar Charger Type: MPPT.Maximum PV Array Power: 5000 W.MPP Range @ Operating Voltage: 120 VDC ~ 430 VDC.Maximum PV Array Open Circuit Voltage: 500 VDC.Maximum Solar Charge Current: 80 A.Maximum AC Charge Current: 60 A.Maximum Charge Current: 80 A.PhysicalDimension, D x W x H (mm): 115 x 300 x 400.Net Weight (kgs): 10.Communication Interface: USB/RS232/RS485/Bluetooth/Dry contact.Included in boxInverter x 1User manual x 1RS232 Communication cable x 1Software CD x 1DC Fuse x 1
