KP1-63A 2P Single-Display Voltage Current Protector

Technical data Rated supply voltage AC220V Operation voltage range AC80V~350V Rated frequency 50/60Hz Flectric current setting range 1~40/63A Rated current 40/63A(subject to product label) >U and <U trip delay 0.5S Reset/start delay 1~600S Voltage measurement accuracy 1%(Not exceeding 1%of the overall range Rated insulation voltage 400V Output contact 1NO Electrical life 10⁵ Mechanical life 10⁶ Protection degree lp20 Pollution degree 3 Altitude ≤2000m Operatintg temperature -50℃~55℃ Humidity ≤50%at40℃(without condensation) Storage temperature -30℃~70℃   Default setting Technical parameter Setting range Step Factory setting Over-current protection value 1~40/63A 0.1A 40/63A Recovery delay time 1~600S 1S 5S Continuous overcurrent protect times A01~A20/oFF A01 oFF   Current specification 15A 25A 32A 50A 63A Rated operating current(In,A) 15 25 32 50 63 Maximum operating current Imax (A,within 10min) 25 30 40 60 80 Max.power of load(kW) 3.6 5.5 7 11 13.9
