KP1-63V 2P Single-Display Voltage Current Protector
$26.04
$47.39
Technical data Rated Supply voltage AC 220V Operation voltage AC 80V-400V(single phase) Rated frequency 50/60Hz Electric current(>A)setting range 1-40/63A/oFF Overvoltage(>U)setting range 230-300V/oFF Undervoltage(<U)setting range 210-140V/oFF Rated curren 40/63A(subject to prodect label) >U and <U trid delay time 0.5S Reset/start delay time 1-600S Voltage measurement accuracy 2%(Not exceeding2%of the overall range) Rated insulation voltage 400V Output contact 1NO Electrical life 10⁵ Mechanical life 10⁶ Protection degree IP20 Pollution degree 3 Altitude ≤2000m Operatintg temperature -50℃~55℃ Humidity ≤50%at 40℃(without condensation Storage temperature -30℃~70℃ Default setting Technical parameter Setting range Step Factory setting Over-voltage protection value 230~300V 1V 280V Under-voltage protection value 210~140V 1V 160V Recovery delay time 1~600s 1s 5s Current Specification 15A 25A 32A 50A 63A Rated Operating current(In,A) 15 25 32 50 63 Max Operating Current lmax(A,within 10min) 25 30 40 60 80 Max powerof load(KW) 3.6 5.5 7 11 13.9
