PHOENIX – 1530485 – Electrical Cables – ICDC-040120 – New Main Category: Electrical | Sub-Category: Cables And Fairleads | Status: New Original Components PHOENIX Part Number: 1530485 | ICDC Internal Part Number: ICDC-040120 1530485 Description: SAC-4P- 5,0-PUR/M5FS 1530485 PHOENIX CONTACT Sensor/actuator cable Reference: SAC-4P- 5,0-PUR/M5FS Code: 1530485 Manufacturer: PHOENIX_CONTACT Key Commercial Data Orderkey 1530485 Packing unit 1 pc Note Made to Order (non-returnable) Catalog page Page 190 (C-2-2017) GTIN 4046356024280 Weight per Piece (excluding packing) 83.400 g Custom tariff number 85444290 Country of origin DE (Germany) Dimensions Length of cable 5 m Ambient conditions Ambient temperature (operation) -25 °C … 80 °C (Plug / socket) Degree of protection IP65 IP67 IP68 General Rated current at 40°C 1 A Rated voltage 48 V AC 60 V DC Number of positions 4 Color handle area black Insulation resistance ≥ 10 GΩ Coding A – standard Standards/regulations M5 connector IEC 61076-2-105 Status display No Protective circuit/component unwired Overvoltage category II Degree of pollution 3 Test voltage 1750 V Insertion/withdrawal cycles ≥ 100 Material Contact material CuSn Contact surface material Au Contact carrier material PUR Material of grip body PUR Material, knurls Nickel-plated brass Sealing material NBR Standards and Regulations Standard designation M5 connector Standards/regulations IEC 61076-2-105 Cable Cable type PUR/PVC black Cable type (abbreviation) 350 Conductor cross section 4x 0.14 mm² (Signal line) AWG signal line 26 Conductor structure signal line 18x 0.10 mm Core diameter including insulation 0.92 mm ±0.02 mm Wire colors brown, white, blue, black Overall twist 4 wires, twisted External sheath, color black RAL 9005 External cable diameter D 3.5 mm ±0.1 mm Smallest bending radius, fixed installation 9 mm Smallest bending radius, movable installation 18 mm Outer sheath, material PUR Material conductor insulation PVC Conductor material Bare Cu litz wires Insulation resistance 100 MΩ*km Conductor resistance 148 Ω/km Nominal voltage, cable 100 V Test voltage, cable 800 Vrms Ambient temperature (operation) -15 °C … 80 °C (cable, fixed installation) -5 °C … 80 °C (cable, flexible installation) Environmental Product Compliance REACh SVHC Lead 7439-92-1 China RoHS Environmentally Friendly Use Period = 25 Contact us to discover 1530485. ICDCSPARES.COM offers new or overhauled original components, ready in stock to be shipped via DHL Express! Call us! Check our Electrical section to discover more about ICDC catalog: a large selection of industrial spare parts including Fuses, Electric Motors, Switches and Cables And Faileads. Are you looking for industrial Cables And Faileads? ICDC offers online a wide selection of Cables And Faileads of the most important OEMs like EATON, ABB and DANFOSS, besides PHOENIX. ICDC, Your Industrial One Stop Shop for Components!
