SCHNEIDER - XALK178F - Electrical Buttons - ICDC-041037 - New

SCHNEIDER – XALK178F – Electrical Buttons – ICDC-041037 – New Main Category: Electrical | Sub-Category: Buttons | Status: New Original ComponentsSCHNEIDER ELECTRIC Part Number: XALK178F | ICDC Internal Part Number: ICDC-041037 XALK178F Description: Presentation Product range Harmony XALK Type of product or component Complete control station Device name XALK product application For control and signaling unit XB5 Ø 22 mm Button panel application Emergency stop function Emergency stop function Base color of the box Light gray (RAL 7035) Cover color Yellow (RAL 1021) Material Polycarbonate Operator type 1 mushroom button Operators description Red without marking 2 NC reset Turn to unlock Control station composition 1 mushroom head button Ø 40 mm, red 2 NC unmarked markings Contact operation Slow opening Technical features Cable entry 1 knockout entry for 0 … 14 mm cable gland 2 knockout entries for Pg 13 and ISO M20 0 … 12 mm cable gland product weight 0.194 kg Resistance to high pressure washing 7000000 Pa at 55 ° C, distance: 0.1 m Positive opening With conforming to EN / IEC 60947-5-1 appendix K Operation stroke 1.5 mm (NC with electrical status change) 4.3 mm (total stroke) Operating force 44 No. Mechanical durability 300000 cycles Connections – terminals Screw clamp terminals, terminals,> = 1 x 0.22 mm² without cable end conforming to EN / IEC 60947-1<br /> tightening torque<br /> 0.8 … 1.2 Nm conforming to EN / IEC 60947-1<br /> Head shape (screw)<br /> Phillips head compatible with Philips no 1 screwdriver Phillips<br /> head compatible with pozidriv No 1 screwdriver Slotted<br /> compatible with flat Ø 4 mm screwdriver Slotted<br /> compatible with flat Ø 5.5 mm screwdriver<br /> Contact material<br /> Silver alloy (Ag / Ni)<br /> Short circuit protection<br /> 10 A cartridge fuse type gG conforming to EN / IEC 60947-5-1<br /> Conventional thermal current in air [Ith] 10 A conforming to EN / IEC 60947-5-1<br /> Rated insulation voltage [Ui] 600 V (pollution degree 3) conforming to EN / IEC 60947-1<br /> Rated impulse withstand voltage [Uimp] 6 kV conforming to EN / IEC 60947-1<br /> Rated operational current [Ie] 3 A at 240 V, AC-15, A600 conforming to EN / IEC 60947-5-1<br /> 6 A at 120 V, AC-15, A600 conforming to EN / IEC 60947-5-1<br /> 0.1 A at 600 V, DC-13, Q600 conforming to EN / IEC 60947-5-1<br /> 0.27 A at 250 V, DC-13, Q600 conforming to EN / IEC 60947-5-1<br /> 0.55 A at 125 V, DC-13, Q600 conforming to EN / IEC 60947-5-1<br /> 1.2 A at 600 V, AC-15, A600 conforming to EN / IEC 60947-5-1<br /> Electrical durability<br /> 1000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc / h, load factor: 0.5 conforming to EN / IEC 60947-5-1 appendix C = 1 x 0.22 mm² without cable end conforming to EN / IEC 60947-1 tightening torque 0.8 … 1.2 Nm conforming to EN / IEC 60947-1 Head shape (screw) Phillips head compatible with Philips no 1 screwdriver Phillips head compatible with pozidriv No 1 screwdriver Slotted compatible with flat Ø 4 mm screwdriver Slotted compatible with flat Ø 5.5 mm screwdriver Contact material Silver alloy (Ag / Ni) Short circuit protection 10 A cartridge fuse type gG conforming to EN / IEC 60947-5-1 Conventional thermal current in air [Ith] 10 A conforming to EN / IEC 60947-5-1 Rated insulation voltage [Ui] 600 V (pollution degree 3) conforming to EN / IEC 60947-1 Rated impulse withstand voltage [Uimp] 6 kV conforming to EN / IEC 60947-1 Rated operational current [Ie] 3 A at 240 V, AC-15, A600 conforming to EN / IEC 60947-5-1 6 A at 120 V, AC-15, A600 conforming to EN / IEC 60947-5-1 0.1 A at 600 V, DC-13, Q600 conforming to EN / IEC 60947-5-1 0.27 A at 250 V, DC-13, Q600 conforming to EN / IEC 60947-5-1 0.55 A at 125 V, DC-13, Q600 conforming to EN / IEC 60947-5-1 1.2 A at 600 V, AC-15, A600 conforming to EN / IEC 60947-5-1 Electrical durability 1000000 cycles, AC-15, 2 A at 230 V, operating rate 1000000 cycles, AC-15, 3 A at 120 V, operating rate 1000000 cycles, AC-15, 4 A at 24 V, operating rate 1000000 cycles, DC-13, 0.2 A at 110 V, operating rate 1000000 cycles, DC-13, 0.5 A at 24 V, operating rate Electrical reliability Λ Λ Environment Protective treatment TH Storage temperature -40 … 70 ° C Operating ambient temperature -40 … 70 ° C overvoltage category Class II conforming to IEC 60536 IP protection degree IP66 conforming to IEC 60529 IP67 IP69 IP69K NEMA degree of protection NEMA 13 NEMA 4X IK degree of protection IK03 conforming to EN 50102 Reference standards EN / IEC 60204-1 JIS C 4520 EN / IEC 60947-5-1 IEC 60364-5-53 EN / ISO 13850 CSA C22.2 No 14 UL 508 EN / IEC 60947-5-5 EN / IEC 60947-5- 4 EN / IEC 60947-1 vibration resistance 5 gn (f = 12 … 500 Hz) conforming to IEC 60068-2-6 impact resistance 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 Packaging Packaging unit type 1 PCE No. of units in pkg. 1 Packing weight (Kg) 168.0 g Packaging height 1 9.7 cm Packaging width 1 7 cm Packaging length 1 7 cm Packaging unit type 2 P06 Packing unit number 2 320 Packing weight 2 67.964 kg Packaging height 2 77 cm Packaging width 2 80 cm Packaging length 2 60 cm Packaging unit type 3 S03 Packing unit number 3 40 Packing weight 3 7.202 kg Packaging height 3 30 cm Packaging width 3 30 cm Packaging length 3 40 cm Contact us to discover XALK178F. ICDCSPARES.COM offers new or overhauled original components, ready in stock to be shipped via DHL Express! Call us! Check our Electrical section to discover more about ICDC catalog: a large selection of industrial spare parts including Fuses, Electric Motors, Switches and Buttons.Are you looking for industrial Buttons? ICDC offers online a wide selection of Buttons of the most important OEMs like EATON, ABB and DANFOSS, besides SCHNEIDER ELECTRIC. ICDC, Your Industrial One Stop Shop for Components!
