PHOENIX CONTACT – 1771202 – Electrical Connectors | ICDC-041185 Main Category: Electrical | Sub-Category: Connectors-Contactors | Status: New Original ComponentsManufacturer: PHOENIX CONTACT | Part Number: 1771202 | ICDC Part Number: ICDC-041185Lead Time: 2 Days to Shipping DHL Express Transit Time 1771202 Description:Contact insert – HC-B 10-EBUS 1771202 PHOENIX HEAVYCON female insert, B10 series, 10-pos., screw connection General For housing HC-B10 Type B10 Product type Contact insert with a fixed no. of positions Number of positions 10 Connection profile 10 PE Insulation characteristics Overvoltage category III Degree of pollution 3 Connection technology Connection technology Screw connection Connection in acc. with standard IEC / EN Conductor connection Connection cross section AWG 20 … 14 20 … 12 (PE screw) Tightening torque 0.5 Nm Stripping length of the individual wire 7 mm Dimensional drawing Width 34 mm Height 37 mm Length 64 mm Rated voltage (III/3) 500 V Rated surge voltage 6 kV Rated current 16 A Flammability rating according to UL 94 V0 Contact material Copper alloy Contact surface material Ag Contact carrier material PA Insertion/withdrawal cycles ≥ 500 Cable structure Stripping length of the individual wire 7 mm Assembly instructions Connectors may be operated only when there is no load/voltage. For housings of type B10. Ambient temperature (operation) -40 °C … 125 °C (including heating up of contacts) Constructional and testing regulations DIN VDE 0627/86 DIN VDE 0110/02.79 DIN VDE 0110-1/04.97 IEC 60664-1, DIN IEC 60512 IEC 60352 Tests DIN VDE 0627/86 DIN VDE 0110/02.79 DIN VDE 0110-1/04.97 IEC 60664-1, DIN IEC 60512 IEC 60352Contact us to discover more about the Connectors by PHOENIX CONTACT code 1771202Are you looking for PHOENIX CONTACT industrial components? ICDCSPARES.COM offers new and overhauled original components, ready in stock to be shipped via DHL Express! Call us! Check our Connectors-Contactors section to discover more about ICDC catalog: a wide selection of industrial spare parts, including Compressors, Flow Control Valves, UPS and Rotary Joints, besides Connectors. ICDC offers online a wide selection of Electrical industrial components of the most important OEMs like EUGEN SEITZ, BECKHOFF, SKF, COPELAND and ALFA LAVAL beyond PHOENIX CONTACT.ICDC, Your Industrial One Stop Shop for Components!
